Sliding Gate Galvanized Steel 16mm U Groove Single Bearing Rebate 78mm Wheel With Support Bracket

Single bearing 78mm x 16mm-U-groove galvanized wheel with support bracket.

The wheel is fabricated in Italy by HI-MOTIONS from high quality C45 medium carbon steel.

D = 78mm

A = 20mm

B = 33mm

C = 90mm

H = 53mm

L = 140mm

F = 120mm

Capacity is 250kg

Travelling distance is 220km.

9mm mounting holes

Item code # 111.80

Image is indicative only.
